Rlaarlo 1/10 Scale Carbon-Fiber Brushless XTS-F10 Rally Car RTR

• XTS-F10 Rally Car replaces the traditional body post design with a removable hatch secured by side skirt latches.
• XTS-F10 Rally Car utilizes a 5-channel 350m transmitter with gyroscope assistance for easy operation, enhancing stability and control for an improved driving experience
•  XTS-F10 Rally Car's body is made from 1.2mm PC material, offering both wear resistance and impact protection. The clamshell quick-release design replaces traditional body posts, enhancing realism and aesthetics
• Frame wheelbase 257mm, using the 190MM conversion kit（RZ079） can be universal a large number of shells, enthusiasts can enjoy DIY fun on the existing chassis shells

- INNOVATIVE DESIGN-

XTS-F10 Rally Car is Rlaarlo's flagship 1/10 scale model, celebrating its 3rd anniversary. With three iterations of upgrades, it blends high-fidelity design and outstanding performance. Synchronized lighting and intricate details enhance its visual appeal, while the powerful motor enables it to conquer various terrains with ease.

- READY TO RUN -

Ready to Run (RTR) competition grade RC is fully assembled with everything needed as well as a 3S (2200 mAh) battery

- KEY FEATURES -

• 3S BRUSHLESS SYSTEM: The 3650-3300Kv brushless motor, paired with a 60A brushless ESC, ensures outstanding performance on high-speed tracks and in complex off-road conditions.
• LIFT-OFF QUICK RELEASE DESIGN: XTS-F10 Rally Car replaces the traditional body post design with a removable hatch secured by side skirt latches. This design enhances stability and reduces vibrations, perfectly capturing a sporty stance and elevating the overall driving experience.
• EASY-ACCESS MODULAR DESIGN: XTS-F10 Rally Car features a cleaner chassis wiring layout and balanced weight distribution. With dual receiver boxes and ESC trays, it supports various modifications, enhancing control and stability.
• BETTER VEHICLE CONTROL: XTS-F10 Rally Car utilizes a 5-channel 350m transmitter with gyroscope assistance for easy operation, enhancing stability and control for an improved driving experience.
• STRONG AND DURABLE CAR SHELL: XTS-F10 Rally Car body is made from 1.2mm PC material for durability and impact resistance. It features pre-painted patterns and multiple realistic components, effectively replicating details of real race cars to enhance authenticity and performance.
• GEOMETRIC STRUCTURAL DESIGN: XTS-F10 Rally Car features an upper and lower dual triangular structure, significantly enhancing chassis rigidity and strength, resulting in a more robust body and improved stability.
• STURDY ALUMINUM ALLOY MATERIAL: XTS-F10 Rally Car's chassis and shock tower are made from high-strength aluminum alloy, offering excellent resistance to deformation and durability. This aluminum chassis effectively handles various terrain challenges, ensuring stability and performance.
• ENHANCED CENTER DIFFERENTIAL: XTS-F10 Rally Car is equipped with a central gear differential that can be adjusted for low traction surfaces like muddy or dusty tracks. Its enhanced sealing structure effectively prevents gravel ingress, protecting the drivetrain and improving overall reliability.

· Dimension: L445mm * W218mm * H178mm

· Wheelbase: 257mm, Track Width: 190mm, Ground Clearance: 28mm

· Tire Size: D75mm * W30mm

· Car Body: 1.2mm Polycarbonate or Lexan

· Body Clip: Flip-up quick-release structure (with reinforced side latches)

· Battery Compartment: 110x36x30mm

· Speed: 50-80KM/H

· Drive System: 4WD

· Transmission Method: Central Differential

· Realistic Parts: Front and Rear Independent Light Buckets, Rear Wing, Front Grille, Hood Air Intake, Roof Air Intake,  Door Handles, Side Mirrors (with Reflective Glass), Side Skirts, Rear Bumper Lip, Exhaust Pipes, Front Bumper Foam

· Light System: Full car linkage lighting

· Shock Tower:4mm 7075 Aluminum, CNC

· Chassis: 2.5mm 6061 aluminum alloy, oxide sandblasted, anodized in black

· Steering Column: 6061 Aluminum Alloy, Anodized Green, Sandblasted

· Front and Rear Differentials: Powder Metallurgy Planetary Gears, 10,000 CST Silicone Oil

· Center Differential: 20,000 CST Silicone Oil

· Shock Absorber: All-Metal Oil filled shocks

· Shock Dimension: Ø13.6*96mm, compressed length 67mm

· Rear Axle: 1144 Carbon Steel, Heat Treated HRC42-46

· Main Driveshaft: Center differential transmission（Carbon Steel）36-42

· Universal Drive Shaft (Steering CVD): 1144 Carbon Steel, Heat Treated HRC42-48

· Steering Column Shaft, Steering Linkage, Rear Dogbones, Main Drive Shaft, Upper Link: 1144 Carbon Steel, Heat Treated HRC36-42

· Motor Mount: Aluminum, support Dia.36mm Series Motor, adjustable

· Differential Output Cup, Spur Gear Output Cup, Spur Gear Input Cup: 40cr 48-52

· Pinion Gear: 0.53M/48P 24-27T Chrome Steel Pinion Gear

· Central Spur Gear: 0.53M/48P 65T Chrome Steel Spur Gear

· Differential  Ring Gear: 1M-34T Chromium Steel Spiral Differential Gear

· Differential  Pinion Gear: 1M-11T Chrome Steel Helical Input Gear

· Differential bevel gear set: Large Sun Gear for Differential, 16T (Powder Metallurgy), Small Sun Gear for Differential, 10T (Powder Metallurgy)

· Battery: 3S 2200mAh 35C LiPo Battery

· Servo: 11kg Waterproof Metal Gear Servo

· Transmitter: 2.4GHz 5-Channel Transmitter (With gyroscope，range up to 350 meters)

· Support Voltage: 6V

· ESC: Sensorless Brushless 60A ESC, supports 2-3S LiPo battery（Carbon fiber fan cover)

· Motor: 3650 Brushless Motor 3300KV

- IN THE BOX -

· Instruction manual *1
·Brand sticker *1
·Carbon fiber version of the paint matching shell sticker*1
·L Hexagonal wrench 1.5MM*1
·L Hexagonal wrench 2.0MM*1
·L Hexagonal wrench 2.5MM*1
·cross socket*1
·Complimentary motor gear 27T*1 + machine meter screws*1
·Differential gasket*2
·ESC double-sided tape*2+switch double-sided tape*2
Battery Tie*1
Battery charging cable *1
